Ripsaw Machine - VH-MJ153 Single/Multi Rip Saw

Home  > Products  > Single/Multi Rip Saw  >  Ripsaw Machine - VH-MJ153 Single/Multi Rip Saw
Ripsaw Machine - VH-MJ153 Single/Multi Rip Saw

Ripsaw Machine - VH-MJ153 Single/Multi Rip Saw

model: VH-MJ153
Price Terms: FOB, CIF
Minimum Order: One piece
Payment Terms: T/T, Others


SPECIFICATION AND MODELMJ153A
Max. Saw blade diameter (mm)Φ 305
Max. working thickness (mm)85
Cutting width (mm)360
Main spindle revolution (r/min)3300
Spindle diameter (mm)Φ 50.8
Feeding speed (m/min)12-22
Feeding motor power (kw)0.75
Main motor power (kg)7.5
Lubricate pump motor power (w)20
Total power (kw)8.6
Working tabie sizer (mm)1550x715
Dimension (mm)1750x945x1400
Net weight (kg)920




Single Rip Saw-Top Saw





Chain plates, guideways using special materials and special refining process. Rail high hardness, good wear resistance.Microcomputer control, automatic lubrication pump for chain plates, key parts of the fixed rail, the point when the quantitative supply, ensure the life of the machine.Multiple anti-kickback device and a transparent side guards to prevent the edge of the skin, flakes flew rebound wounding.Specially designed bilaterally by foot, to facilitate users to exchange used to prevent track link long-term impact of the use of unilateral precision machining.



Feeding chian、Raill system
Special material conveying chain, guide rail to ensure Special material conveying chain, guide rail to ensure the accuracy of delivery and improve its service life. the accuracy of delivery and improve its service life.

Auxiliary roller
5 sets of pressing wheel device to ensure the stability of the wood in the conveying process.


Lnfred alignm ent devincecan enable the saw to find its accurate position Effciency.



Accura te fence and lock system
The cast iron fence slide on the hard-chromium The cast iron fence slide on the hard-chromium treatment round bar together with the lock system, that is providing accurate reading and position of the fence. the fence.

Double Anti-kickback finger protection
Dual anti rebound device to improve the safety of operation.

Automatic lubrication
Automatic controlled oil pump provides lubrication to all major parts to extend the machine service life.
